벡트론 P9

벡트론 P9

The Accelerator
3,000,000 원

벡트론 P9은 10초 안에 접어서 열차, 자동차, 책상 아래에 둘 수 있는 최고의 전기 자전거입니다. 전기 구동 장치를 사용하면 20인치 휠도 700c만큼 빠르게 달릴 수 있습니다. 즉 주행자는 작은 휠이 가지는 모든 이점-컴팩트한 크기, 중심부의 낮은 무게중심, 급가속, 방향 조종이 용이한 핸들링, 넉넉한 수납 공간-을 큰 휠 속도로 누릴 수 있다는 것입니다.P9은 9단 소라 구동계를 장착하며, 도심 주행에 필요한 모든 장비를 갖추고 있습니다. TERN 카고랙, VALO 라이트, 앞뒤로 장착 가능한 펜더는 모든 계절의 통근에 적합하도록 고안된 것입니다.

  • Bafang의 M400 Drive System – 250W의 반응 속도 및 신뢰성 높은 전력 소비량
  • 시마노 Sora 구동계는 정확하고 믿을 수 있습니다.
  • 사계절을 제동을 위한 유압식 디스크 브레이크
  • 150루멘의 Tern Valo 라이트, 24시간 가시성 확보
  • 최대 90km 까지 커버할 수 있는 400wh 배터리
  • 147cm에서 195cm사이의 신장까지 적합한 Andros 스템
옵션 액세서리 사진
Black/Dark Grey
Dark Red
20인치 휠
Electric
중급

테크놀로지

제품 리뷰

CityRide

Nous voilà séduits par les performances du moteur central Bafang Max Drive.

Sur le plan du pilotage le Vektron p9 procure beaucoup de Plaisir. Son coté compact lui permet de se faufiler aisément dans le flot de la circulation tout en restant bien stable grace à un centre de gravité bas. Quant à la position de pilotage, elle est confortable et ne procure pas la moindre tension musculaire.

[We are seduced by the performance of the mid-motor Bafang Max Drive.

In terms of riding the Vektron p9 provides a lot of fun. Its compact size allows it to sneak easily into the traffic flow while remaining stable thanks to a low center of gravity. As for the steering position, it is comfortable and does not provide the slightest muscle tension.]

Read more

Elektrobike

62 E-Bikes in 8 Kategorien hat die Elektrobike-Test-Crew auf der Straße getestet (…). Alle Testsieger aus dem Elektrobike-Test im Überblick:
(…)
Kompakt-E-Bike: Tern Vektron P9

[The Elektrobike Test Crew has tested 62 ebikes in 8 categories (…). All test winners at a glance:
(…)
Best compact ebike: Tern Vektron P9]

Read more

Elektrobike

Auf seinen kleinen Rädern rollt das Tern Vektron sehr wendig, aber nicht nervös. […] Für Komfort sorgen die voluminösen Reifen und die ergonomische Sattel-Lenker-Kombination. […] Das Vektron sichert sich den Kompakt-Testsieg.

[On its small wheels, the Tern Vektron is agile, but not nervous. […] Comfort is ensured by the voluminous tires and an ergonomic cockpit. […] The Vektron wins our the compact category test.]

Read more

Focus.de

Egal für welche Motorvariante man sich entscheiden mag, handelt es sich beim Vektron um ein erfreulich gut gemachtes E-Bike, welches als Besonderheiten hochvariable Einstellmöglichkeiten für Lenker und Sattel sowie einen Faltmechanismus bietet, der raumoptimiertes Verstauen und den einfachen Transport erlaubt.

[No matter which variant of engine you choose, the Vektron is a pleasingly well-made e-bike that offers highly variable adjustment options for the handlebar and saddle as well as a folding mechanism that allows space-optimized stowage and easy transport.]

Read more

ElektroRad

Das Vektron P9 ist sehr variabel einsetzbar – ein wirklich praktisches Rad zum attraktiven Preis.

[The Vektron P9 is very versatile – a really practical bike at an attractive price point.]

Read more

Velomotion

Das Tern Vektron P9 regt nicht nur Verkehrsexperten zum Träumen an, es funktioniert auch richtig gut.

[Not only is the Vektron P9 an urban-planner’s dream, it also rides really well.]

Read more

BikeBiz

With a fleet of 100 Tern Vektron e-bikes spread across 13 ships, over 2,200 Grand Circle Cruise Line and OAT customers have had enjoyed the e-bike tour while on holiday.
Read more

MyBusinessLab

Tern per i possessori di eBike è anche garanzia di sicurezza, dato che la bici pieghevole è sempre al seguito e non necessita di essere lasciata in strada.

[Tern for e-bike owners is also a guarantee of safety since the folding bike is always with you and doesn’t have to left on the street.]

ElectricBikeReview.com

. . . has plenty of cargo space, and there’s just this stiffness feel . . . a very solid feel. . . .

Read more


제원

Miscellaneous
Color:
Black/Dark Grey
Dark Red
Wheel Size:
20인치 휠
Speeds:
1 x 9
Frame Sizes:
One size
Gear Inches:
33" - 97" (2.65 - 7.72 m)
Distance: Seatpost to Handlebar:
Min. 620 mm (24.4") Max: 690 mm (27.2")
Distance: Saddle to Pedal:
Min. 680 mm (26.8") Max: 1110 mm (43.7")
Folding Size:
41 x 86 x 68 cm (16.1" x 33.9" x 26.8")
Folding Time:
10 sec
Weight:

22.6 kg (49.8 lb)

Suggested Rider Height:
147 - 195 cm (4'10" - 6'5")
기본자료
Max Load Weight:
105 kg (230 lb)
차체
차체:
Tern Vektron, hydroformed aluminum, OCL+ joint, 3 patented technologies
포크:
Tern Tarsus, 6061-Al, hydroformed
조종계통
핸들포스트:
Tern Physis 3D (G2), 3D forged, 5 patented technologies, 12°, 320 mm
스템:
Tern Andros (G2), adjustable, forged construction, patented technology
헤드셑:
Tern Flux, cartridge bearings, Physis integrated
핸들바:
Flat bar, 6061-Al, Tern Andros adapted
그립/바테잎:
BioLogic Arx
안장:
Tern Porter, patented GripPad design
시트포스트:
Tern Telescope, 34.9 mm, Lite 2014-AL
시트포스트 클램프:
Oversize, 6061-Al, 2 pc
브레이크계통
앞 브레이크:
Shimano, hydraulic disc
뒤 브레이크:
Shimano, hydraulic disc
브레이크 레버:
Shimano, hydraulic disc
브레이크 케이블과 하우징:
Shimano, hydraulic disc
휠계통
앞 허브:
Shimano disc
뒤 허브:
Shimano disc
스포크와 니플:
Stainless steel
림:
Kinetix Comp, for disc
타이어:
Schwalbe Big Apple, Performance Line, 55-406, puncture protection, Reflex
구동계통
기어장치:
Shimano, 1 x 9 spd, trigger
뒤 변속기:
Shimano Sora
크랭크세트:
Vektron custom, forged 6061-AL crankarm
카셋트/프리휠:
Shimano 11-32T, 9 spd
바텀 브라켓:
Motor integrated
체인:
9 spd, DHT for eBike, GST corrosion resistant coating
페달:
LiteForm QR, alloy body, QR right/standard left
변속 케이블과 하우징:
Jagwire LEX-SL, slick treatment, alloy ferrules
E-System
Motor:
Bafang M400 Drive System, 36 V/250 W, max speed 25 kph (EU); max speed 20 mph (US), max torque 80 Nm
Battery:
Bafang M400 Drive System Battery, 400 Wh, Panasonic cells
디스플레이:
Bafang M400 Drive System Display, 5 mode selectable, walk assist
Range:
40-90 km (25-56 mi)
Bells & Whistles
Bell:
Aluminum
체인가드:
n/a
킥스탠드:
DoubleStand, center mount
클립 시스템:
Magnetix 2.0
러기지 소켓:
Yes
전조등:
Tern Valo Direct, integrated, 41 lux/150 lumens
후미등:
Herrmans H-Trace / H-Trace Mini, for eBike
흙받이:
SplashGuard, stainless hardware
짐받이:
Opt: Tern Cargo Rack
악세서리:
Pedal Holder
